Cartridge Exclusive Grease
· Compact and lightweight design with built-in depressurization features for the supply of quantitative grease
· This grease pump is assembled with the metering valve and discharges the quantity of grease on time.
· Easy to replace cartridge to recharge grease, maintaining a clean environment
· A grease pump that is designed to be excellent at lubrication points, such as the LM guide and ball screw
· Designated grease (NLGI Grade 000, 00, 0, 1) using pump
| MOTOR SPECIFICATION | |
|---|---|
| Out Put | 8W |
| RPM | 6500 |
| Voltage(V) | DC 24V |
| Current(A) | 0.8A |
| GREASE SPECIFICATION | ||
|---|---|---|
| Cartridge Vol. (ml) | 700 | |
| Constency (NLGI Grade) | 전용 | 000 |
| General | 00, 0, 1 | |
| Worked Penetration 25℃ (NLGI 000~1) |
310~475 | |
| Density (g/cm²,15℃) (NLGI) |
0.89 | |
| PUMP SPECIFICATION | |
|---|---|
| Operating Temperature | -10℃ ~ +45℃ |
| Discharging Pressure (kg/cm²) | HMG:80, LMG:50 |
| Discharging Volume (cc/min) | 7 |
| Power Consumption | 24W |
| Interval Time | More than 10 minutes |
| Discharging Port | PT1/8″ |
| Weight (Kg) | 2.5 |
Metering Cartridge Auto Grease Pump
· Pump with high viscosity grease supply used in various industrial machines
· t is used in combination with a quantitative distribution valve because it has a de-pressure valve function in the pump
· On-time and quantitative grease is supplied to various locations in combination with a quantitative distribution valve
· This pump is used in a Greek cartridge method, and maintains an economical and clean environment
· Use our designated grease (NLGI #00 to #2.)
| PUMP SPECIFICATION | |
|---|---|
| Operating temperature | -10°C ~ +45°C |
| Discharge Pressure (kgf/cm2) | 110 +_10 |
| Discharge Volume (cc/min) | 10 |
| Driving Time | Continuous Energization |
| Interval Time | No Restriction |
| Discharge Port | PT 1/8 |
| Weight (Kgf) | 2.6 |
| MOTOR SPECIFICATION | ||
|---|---|---|
| Voltage (V) | DC24V | |
| RPM | 6500 | |
| Out Put (W) | 36W | |
| Current (A) | 1.5A | |
| HANSUNG ORIGINAL GREASE SPECIFICATION | |
|---|---|
| Cartridge Vol.(cc) | 700 |
| Consistency Grade | NLGI #00~2 |
| WORKED PENETR.(25°) | ~ 295 |
※ For special grease, please contact our technical department at our headquarters.
* Attach to the end of the metering valve piping and output a pump stop signal
| Technical Data | |
|---|---|
| Operating Pressure | 40±2kgf/cm² |
| Reset Pressure | 30±2kgf/cm² |
| Electrical Ratings | 0.1mA~5mA, Max.42V |
| Operating Temp | -25℃ ~ +85℃ |
| Operating per minute | 60 (Cycle/min) |
| Endurance | Above 1,000,000 Cycle |
| IP Grade | IP65 |
| Weight (g) | 47 |
Cartridge Exclusive Grease
· HCG model is a high-quality universal grease. It can be used even during extreme pressure, heavy duty.
· It is and has excellent abrasion resistance, also has water resistance
· HCG grease has a low-capacity lubricating effect for a long time
Compeact Elextric Grease Pump Type
HGP-16 type is a reduction motor-driven grease pump that supplements the problems of existing large pumps, and is a compact and powerful controller-equipped grease pump.
· It is compact, lightweight and affordable.
· A controller-equipped grease pump.(HGP-(□))
· It has to used with a multi-stage distributor combination.
· For use in two line systems, it is used in conjunction with change over valves.
※ If there is no discharge, remove air by opening the air vent plug’s plug.
※ Grease level switch is an order specification
※ HGP-16(S) is an order specification used for external control.
HGP-□E > for external control
HGP-16 Etype has the same pump structure as the traditional HGP-O, but uses an external control method rather than an internal controller to increase the user’s range of choices.
| Type | HGP-□ | HGP-□C |
|---|---|---|
| TANK CAPACITY | 2Liter | 200, 500, 800cc |
| WEIGHT | 5kg | 4.5kg |
| USING GREASE | #000~#1 | |
| NUMBER OF OUTLET | 24 | |
| PACKING SIZE (cm) | 25(W) x 17(L) x 37(D) | |
|---|---|---|
| WEIGHT (kg) |
PUMP | 5 |
| PACKING | 6 | |
| PUMP SPEC. | ||||||||
|---|---|---|---|---|---|---|---|---|
| MODEL | HGP-16 | HGP-16(S) | HGP-16E | HGP-40E | ||||
| PUMP TYPE | PISTON | |||||||
| DIS. PRESSURE(kg/cm²) | 120 | 120 | 160 | 100 | ||||
| DIS. AMOUNT(cc/min) | 16 | 16 | 16 | 40 | ||||
| USING PRESSURE(kg/cm²) | 60 | |||||||
| INTERVAL | 1~32Hr | External control | ||||||
| DISCHARGE TIME | 10~120SEC | |||||||
| MOTOR SPEC. | ||||||||
| OUTPUT | 100W | 25W | 25W | |||||
| PHASE | 1ø | 1ø | 1ø | |||||
| VOLTAGE (V) | 110 | 220 | 110 | 220 | 110 | 220 | ||
| CURRENT (A) | 3 | 1.5 | 0.6 | 0.3 | 0.6 | 0.3 | ||
Air Drive Pump Type
HGP- type is operated by a supply of compressed air, and is a continuous grease discharge pump. The pump can be arbitrarily controlled by opening and closing the air passage. An air drive pump that can change the discharge quantity and discharge pressure by controlling the pressure of the supplied air.
· It offers high-pressure deliveries suitable for long-distance oil supply.
· It has to be used with a multi-stage distributor combination.
· The mentioned discharge per minute requires more than 5kg/cm² pressure in the supplied compressed air.
※ If there is no discharge, remove air by opening the Air Vent Plug’s Plug.
※ Grease level switch is an order specification. (HGP-□F type)
HGP-□ Cuses cartridge type grease, which does not require grease filling, is easy to disassemble and assemble, and prevents the entry of foreign substances and air that usually occurs during fillings.
| MODEL | HGP-720 |
|---|---|
| PUMP TYPE | PISTON |
| OPERATING PROCESS | AIR DRIVE |
| DISCHARGE AMOUNT(cc/st) | 0.4 |
| DISCHARGE PRESSURE(kg/cm²) | MAX. 200 |
| AIR PRESSURE | 5kg/cm² |
| TANK CAPACITY | 2 LITER |
| USING GREASE | #000~#1 |
| PACKING SIZE (cm) | 25(W) x 16(L) x 33(D) | |
|---|---|---|
| WEIGHT (kg) |
PUMP | 3 |
| PACKING | 4 | |
Manual Pump
MG-10, the forced oil supply manual grease pump, adopts a concentrated lubricating oil supply method to allow suitable planning of oil supply quantities, and increases productivity through reduced oil supply costs and machine stoppage time. The elimination of risks that can happen during grease injections allows safer management of oil supply.
– It allows suitable planning of oil supply quantities, and the use of a HU-R type grease spray allows multi-stage oil supply.
– It can extend the lifespan of machines and bearings.
– It can prevent the entry of contaminated grease.
– If there is no grease discharge, unscrew the air vent screw(-) and remove the air inside the body.
| PUMP TYPE | PISTON |
|---|---|
| DIS. PRESSURE | MAX. 130kg/cm² |
| DISCHARGE AMOUNT | 1.0cc/st |
| TANK CAPACITY | 600cc |
| SIZE OF OUTLET | PT 1/8″ |
| USING GREASE | #000~#1 |
| REMARK | – |
| PACKING SIZE (cm) | 32(W) x 10(L) x 14(D) | |
|---|---|---|
| WEIGHT (kg) |
PUMP | 3 |
| PACKING | 4 | |
Manual Pump
The HM pump is a compact manual grease pump, and is used to supply smaller discharge quantities compared to automatic pumps, and is applied to systems with relatively small lubricating oil supplies. The maximum discharge pressure is divided into 100kg/cm² or 210kg/cm² depending on the quantity of discharge, and the tank is separated into a 2liter or a 4liter. Exchange of the discharge part’s block allows attachments of switching sides when applying single line and two line. The simple operation method means less breakdowns, and easier repairs and maintenance.
| TYPE | HM□-21 | HM□-41 | HM□-22 | HM□-42 |
|---|---|---|---|---|
| DISCHARGE AMOUNT (cc/st) | 7 | 3.5 | ||
| MAX. DISCHARGE PRESSURE (kg/cm²) | 100 | 210 | ||
| TANK CAPACITY (Liter) | 2 | 4 | 2 | 4 |
| WEIGHT (kg) | 8 | 9 | 8 | 9 |
| MODEL | H1 | H2 | ||
|---|---|---|---|---|
| MIN. | MAX. | |||
| HM□-21 | HM□-22 | 350.5 | 526.5 | 324.2 |
| HM□-41 | HM□-42 | 550.5 | 726.5 | 524.2 |
Manual Pump
The HM pump is a compact manual grease pump, and is used to supply smaller discharge quantities compared to automatic pumps, and is applied to systems with relatively small lubricating oil supplies. The maximum discharge pressure is divided into 100kg/cm² or 210kg/cm² depending on the quantity of discharge, and the tank is separated into a 2liter or a 4liter. Exchange of the discharge part’s block allows attachments of switching sides when applying single line and two line. The simple operation method means less breakdowns, and easier repairs and maintenance.
| TYPE | HM□-21 | HM□-41 | HM□-22 | HM□-42 |
|---|---|---|---|---|
| DISCHARGE AMOUNT (cc/st) | 7 | 3.5 | ||
| MAX. DISCHARGE PRESSURE (kg/cm²) | 100 | 210 | ||
| TANK CAPACITY (Liter) | 2 | 4 | 2 | 4 |
| WEIGHT (kg) | 8 | 9 | 8 | 9 |
| MODEL | H1 | H2 | ||
|---|---|---|---|---|
| MIN. | MAX. | |||
| HM□-21 | HM□-22 | 350.5 | 526.5 | 324.2 |
| HM□-41 | HM□-42 | 550.5 | 726.5 | 524.2 |
Sequential Distributor
The HU-R type distributor automatically supplies fixed quantities of pressurized oil to each discharge outlet trough the continuously operating piston, and can operate continuously with grease movement. The distributor operated independently, and the discharge varies between 2-8,10,12 according to the discharge outlet.
HUR Type distribution valve has an inlet that can be selected for use in either a side type (HU-□R) or top type (HU-□RS) as shown in the image.
The HU-RL type distributor’s operation can be detected by attaching a limit SAW to the Indicator.
· When assembling the pipes, if there are extra discharge outlets, never block them with a plug. “※Operation is not possible when blocked with an arbitrary plug.”
· Unnecessary discharge outlets need to be piped using the attachments. (But, the pipe connected with attachments will have double the discharge quantity.)
· Once the distributor has completed 1 cycle, the Indicator moves forward/backward if any pipe is blocked, and does not operate, to allow visual discrimination of any problems.
* Warning: Do not use soap-based grease.
| MODEL | HU-R(L) | HU-R(L) |
|---|---|---|
| NUMBER OF OUTLET | 2-8 | 10, 12 |
| DISCHARGE AMOUNT | 0.3cc/stroke | |
| DIS. PRESSURE | MIN. 15kg/cm² MAX. 150kg/cm² |
|
| Operating Grease(NLGI Grade) | 000, 00, 0, 1, 2 | |
| PACKING SIZE(cm) | 13(W) x 8(L) x 8(D) | |
|---|---|---|
| WEIGHT(kg) | DISTRIBUTOR | 1 |
| PACKING | 1 | |
Distributor
· DV Type distributors are two line system distributors.
· Lubricant is supplied appropriately to each lubricating point by the pressure of lubricant transferred in tum from main supply line
· Operation of distributing valve is checked by indicator.
· Amount of grease can be adjusted as desired by the adjusting screw.
– Accurate lubrication sliding unit is finished in high precision, which enables accurate weighing and lubricating.
– Robust and highly endurable.
– Maximum working pressure 21MPa application of high pressure improves reliability of lubrication and enables lubrication in a broad range
| Distributor Size | 30 | 40 | 50 | 60 |
|---|---|---|---|---|
| MAX. DISCHARGE PRESSURE (MPa) | 21 | |||
| APPLICABLE GREASE | Centralized Lubrication Grease NLGI Consistency Number #0~#2 | |||
| MIN. DISCHARGE PRESSURE (MPa) | 1 | 1 | 1 | 1 |
| DISCHARGE VOLUME (cm³/stroke MAX) | 1.2 | 2.5 | 5 | 14 |
| DISCHARGE VOLUME (cm³/stroke MIN) | 0.2 | 0.6 | 1.2 | 3 |
| ADJUSTING AMOUNT PER ROTATION OF ADJUSTING SCREW (cm³) | 0.06 | 0.10 | 0.15 | 0.68 |
| ASSEMBLY BOLT SIZE | M8 x 60 | M8 x 60 | M8 x 65 | M8 x 75 |
| USING TEMPERATURE | Standard:-20~100℃ High:-40~200℃ | |||
※ When using the valve of Oil, set the pressure below 10MPa.
| Type | DV-31 | DV-32 | DV-33 | DV-34 | DV-41 | DV-42 | DV-43 | DV-44 | DV-51 | DV-52 | DV-53 | DV-54 | DV-61 | DV-62
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Weight(kg) | 0.8 | 1.4 | 1.8 | 2.3 | 1.0 | 1.9 | 2.7 | 3.2 | 1.4 | 2.4 | 3.5 | 4.6 | 2.4 | 4.2 |
Distributor
· DW Type distributors are two line system distributors
· The ports are doubled in number from single discharging type (1 port/element) to dual discharging type (2 ports/element) for saving space
– Distributing valves can be reduced half in number with reference to required number of lubricating ports, which simplifies installation and piping
– Maximum working pressure 21MPa application of high pressure improves reliability of lubrication and enables lubrication in a broad range.
– DW-30, 40, and 50 type all have the same installation dimension, so that distributing valve can be connected with each other and size can be changed easily.
– Robust and highly endurable.
| Distributor Size | 20 | 30 | 40 | 50 |
|---|---|---|---|---|
| MAX. DISCHARGE PRESSURE (MPa) | 21 | |||
| APPLICABLE GREASE | Centralized Lubrication Grease NLGI Consistency Number #0~#2 | |||
| MIN. DISCHARGE PRESSURE (MPa) | 1.2 | 1 | 1 | 1 |
| DISCHARGE VOLUME (cm³/stroke MAX) | 0.6 | 1.2 | 2.5 | 5.0 |
| DISCHARGE VOLUME (cm³/stroke MIN) | 0.15 | 0.2 | 0.6 | 1.2 |
| ADJUSTING AMOUNT PER ROTATION OF ADJUSTING SCREW (cm³) | 0.04 | 0.06 | 0.10 | 0.15 |
| ASSEMBLY BOLT SIZE | M8 x 60L | M8 x 75L | ||
| USING TEMPERATURE | Standard:-20~100℃, High:-40~200℃ | |||
※ When using the valve of Oil, set the pressure below 10MPa.
| Type | DW-22 | DW-24 | DW-26 | DW-28 | DW-32, 42, 52 | DW-34, 44, 54 | DW-36, 46, 56 | DW-38, 48, 58 |
|---|---|---|---|---|---|---|---|---|
| Weight(kg) | 0.5 | 0.8 | 1.1 | 1.4 | 1.4 | 2.4 | 3.4 | 4.4 |
Distributor
· DW Type distributors are two line system distributors
· The ports are doubled in number from single discharging type (1 port/element) to dual discharging type (2 ports/element) for saving space
– Distributing valves can be reduced half in number with reference to required number of lubricating ports, which simplifies installation and piping
– Maximum working pressure 21MPa application of high pressure improves reliability of lubrication and enables lubrication in a broad range.
– DW-30, 40, and 50 type all have the same installation dimension, so that distributing valve can be connected with each other and size can be changed easily.
– Robust and highly endurable.
| Distributor Size | 20 | 30 | 40 | 50 |
|---|---|---|---|---|
| MAX. DISCHARGE PRESSURE (MPa) | 21 | |||
| APPLICABLE GREASE | Centralized Lubrication Grease NLGI Consistency Number #0~#2 | |||
| MIN. DISCHARGE PRESSURE (MPa) | 1.2 | 1 | 1 | 1 |
| DISCHARGE VOLUME (cm³/stroke MAX) | 0.6 | 1.2 | 2.5 | 5.0 |
| DISCHARGE VOLUME (cm³/stroke MIN) | 0.15 | 0.2 | 0.6 | 1.2 |
| ADJUSTING AMOUNT PER ROTATION OF ADJUSTING SCREW (cm³) | 0.04 | 0.06 | 0.10 | 0.15 |
| ASSEMBLY BOLT SIZE | M8 x 60L | M8 x 75L | ||
| USING TEMPERATURE | Standard:-20~100℃, High:-40~200℃ | |||
※ When using the valve of Oil, set the pressure below 10MPa.
| Type | DW-22 | DW-24 | DW-26 | DW-28 | DW-32, 42, 52 | DW-34, 44, 54 | DW-36, 46, 56 | DW-38, 48, 58 |
|---|---|---|---|---|---|---|---|---|
| Weight(kg) | 0.5 | 0.8 | 1.1 | 1.4 | 1.4 | 2.4 | 3.4 | 4.4 |
Grease Metering Valve
· HGMV series is positive displacement injector valve with high reliability.
· It is available for various combination because it is using exclusive distributor. (Can be used 1~16 ports)
| METERING GREASE VALVE SPECIFICATION | ||||||||
|---|---|---|---|---|---|---|---|---|
| HMGC CODE NO. | 3 | 5 | 10 | 20 | 30 | 50 | 100 | |
| HMGC (OneTouch) |
Discharging Volume(cc/st) | 0.03 | 0.05 | 0.1 | 0.2 | 0.3 | 0.5 | 1.0 |
| Operating Pressure (kg/cm²) | 25 | |||||||
| Reset Pressure (kg/cm²) | 15 | |||||||
